XBT-1064-NGXX - 75Ω BNC Socket 6GHz Cable Bulkhead - Cambridge Electronics Industries

6GHz DIN 1.0/2.3 (m) to BNC (f) Coaxial Cable Assembly – RG59 Cable

These coaxial cable assemblies are designed to allow the user to interface between a BNC and DIN 1.0/2.3 connection types. The materials, connectors, cables and construction methods utilised ensure that these cable assemblies meet the high speed, high definition demands of 6GHz CoaXPress machine vision applications, as well as 6G-SDI Broadcast standards.

Cable Length (XXXXX) is the required cable length in mm E.g. 1 metre = 01000. Standard lengths are from 1M to 10M in metre intervals, but other lengths are available on request. The SO part number signifies RG59 cable, but other cables can be used.

3GHz BNC Bulkhead (f) to Micro BNC (m) Coaxial Cable Assembly – Belden 1855A Cable

The CA-BCBHBP-MO-XXXXX is a BNC bulkhead socket to Micro BNC plug coaxial cable assembly, which is suitable for frequencies up to 3GHz. The XXXXX in the part number denotes the length in mm and as these cables are made in-house, they can made to any length required. The patch cable uses Belden 1855A cable, which is rated at 75Ω impedance.

These cable assemblies are designed to meet the requirements of 3G-SDI Broadcast standards as well as the machine vision (CoaXpress) CXP-3 standard.

3GHz BNC Bulkhead (f) to DIN 1.0/2.3 (m) Coaxial Cable Assembly – Belden 1855A Cable

The CA-BCBTTP-MO-XXXXX is a BNC bulkhead socket to DIN 1.0/2.3 plug patch coaxial cable assembly, which is suitable for frequencies up to 3GHz. The XXXXX in the part number denotes the length in mm and as these cables are made in-house, they can made to any length required. The patch cable uses Belden 1855A cable, which is rated at 75Ω impedance.

These cable assemblies are designed to meet the requirements of 3G-SDI Broadcast standards as well as the machine vision (CoaXpress) CXP-3 standard.

TLG 110 – Hand Crimp Tool for Coaxial Connectors (Green)

The TLG110 is a crimp tool specifically designed to allow a wide range of cable styles to be easily terminated to the following Cambridge Electronic Industries parts:

XBT-1062-NGAB
XBT-1062-NGBA
XBT-1062-NGAS
XBT-1068-NGAS

TLG 111 – Hand Crimp Tool for Coaxial Connectors (Yellow)

The TLG111 is a crimp tool specifically designed to allow a wide range of cable styles to be easily terminated to the following Cambridge Electronic Industries parts:

XBT-1066-NGBA
XBT-1064-NGBA
XGT-8000-NGAS
