The XHT-9015-NGAB is a cable mounted DIN 1.6 / 5.6 plug connector and is suitable for cables in the group AB, which includes RG59 and 1505A. The connector supports frequencies up to 1GHz.
| Impedance | 75Ω |
| Frequency Range | 0 – 1GHz |
| Metal Parts | Brass / Ni |
| Centre Pin | BeCu / Au |
| Insulators | PTFE |
| Mounting Type | Cable Mounted |
| Cable Types | Cable Group AB (RG59 – 1505A – RG140/U- 4505R) |
