Product Code: ZCP-12-CST-GGDF-I

The ZCP-12-CST-GGDF-I is an SMA cable mount plug which offers up to 12GHz in frequency. The plug is designed to fit cable group AN, which includes RG178. The connector has a PEEK insulator so it makes it suitable for applications where signal leakage is undesirable.

This connector was previously available as part number XCT-6021-NGDF.

Impedance 50Ω
Frequency Range 0 -12.4GHz
Connector Type Male
Metal Parts Brass / Au
Centre Pin Brass / 30µ Au
Insulators PEEK
Mounting Type Cable
Processing Crimp
