The ZQS-06-CST-NNAD is an FME (For Mobile Equipment) connector and offers excellent performance from DC to 6GHz using RG174 cable. This miniature connector is also rated to IP67, so protects from moisture and dust ingress.
| Impedance | 50Ω |
| Frequency Range | 0 – 6 GHz |
| Connector Type | Female |
| Body Finish | Brass / Ni |
| Centre Pin | Brass / Ni / Au |
| Insulators | PTFE |
| Seal | Silicon Rubber |
| Processing | Crimp |
| Mounting Type | Cable Mounted |
| Cable Types | Cable Group AD RG188A/U, RG316/U and RG174/U |
