C-SX-191 – DIN 1.0 / 2.3 Bulkhead Socket to DIN 1.0 / 2.3 Socket Adaptor

Product Code: C-SX-191

The C-SX-191 is a DIN 1.0/2.3 female bulkhead to DIN 1.0/2.3 female adaptor. This is a precision 75Ω adaptor which is suitable for frequencies up to 6GHz.. Each adaptor is supplied with a circular nut.

Electrical

Impedance	75Ω
Frequency Range	0 – 6GHz
Working Voltage	250Vrms
Dielectric Withstanding Voltage	750Vrms
Reflection Factor (VSWR)	1.17 (max) DC – 6.25GHz

Material

Metal Parts	Brass / Au or Ni
Centre Pin	BeCu / 10µ Au
Insulators	PTFE

Environmental

Temperature Range

-65 to +85°C

Mechanical

Mating Cycles

500

General Information

Hardware

Supplied with a 2 slot circular nut
