This high quality 3 pin panel mount XLR plug features a square die cast shell constructed from zinc alloy and then finished with a black chrome coating, providing outstanding strength, dimensional stability, and long term durability. Designed with rear solder buckets for convenient cable termination, it offers a compact and flexible interconnect solution suitable for a wide range of applications.

The precision machined brass contacts are gold plated to deliver superior conductivity, corrosion resistance, and a long service life. The shell also features a grounding pin for additional protective shielding for signal integrity. Ideal for professional audio, broadcast, and industrial signal applications.

Key Features:

• 3-pin XLR plug (male), panel-mount type
• Die cast zinc alloy with black chrome coating shell
• Straight pins for PCB mounting
• Precision-machined brass contacts with gold plating
• Excellent electrical performance and corrosion resistance

This high quality 3 pin panel mount XLR plug features a square die cast shell constructed from zinc alloy and then finished with a nickel plating, providing outstanding strength, dimensional stability, and long term durability. Designed with rear solder buckets for convenient cable termination, it offers a compact and flexible interconnect solution suitable for a wide range of applications.

The precision machined brass contacts are nickel plated to deliver superior conductivity, corrosion resistance, and a long service life. The shell also features a grounding pin for additional protective shielding for signal integrity. Ideal for professional audio, broadcast, and industrial signal applications.

Key Features:

• 3-pin XLR plug (male), panel-mount type
• Die cast zinc alloy with nickel plated shell
• Straight pins for PCB mounting
• Precision-machined brass contacts with nickel plating
• Excellent electrical performance and corrosion resistance
